NOVA SPECIFIC MOUNTING
NGU550 - GALVANIZED STEEL MAX
W: 550 lbs./249 kg. D: 45”/114cm H: 5”/13cm
Galvanized Steel Base - Concrete, Paver Filled (Included)
MS
G-SERIES SPECIFIC MOUNTING
36G-SQ/18ST2 - GALVANIZED STEEL PLATE W: 200 lbs./90 kg. D: 36”/91cm H: .5”/12.7mm
Accommodated Mast: 2”/50mm (18ST2) Use: FREE-STANDING OR TABLE
CAN BE STACKED
18ST2 STEM REQUIRED OPTION: ADD WHEELS +W
GS-480/18ST2 - GALVANIZED STEEL WHEEL BASE W: 80 lbs./36 kg. D: 34”/86cm H: 11”/28cm
Accommodated Mast: 2”/50mm (18ST2)
Galvanized Steel Base - Concrete Paver Filled
SHIPS EMPTY
BK WH BZ MS
NGU-DP - DIRECT SURFACE MOUNTING PLATE W: 20 lbs./9 kg. D: 16”40cm H: .5”/12.7mm
Use: DIRECT SURFACE INSTALLATION INSTALLATION HARDWARE NOT INCLUDED
NGU-IG - IN-GROUND MOUNT
W: 18 lbs./8 kg. D: 8”/20cm H: 20”/50cm
Use: IN-GROUND MOUNT INSTALLATION
Can be installed into soft soil, concrete or hard clay. Please consult a licensed professional for in-ground or surface mounting installations.
36G/18ST2 - GALVANIZED STEEL PLATE
W: 150 lbs./68 kg. D: 36”/91cm H: .5”/12.7mm
Accommodated Mast: 2”/50mm (18ST2) Use: FREE-STANDING OR TABLE
CAN BE STACKED
18ST2 STEM REQUIRED
All bases have a +/- 10 lbs (4.5kg.) weight tolerance based on a variety of variables. Overall diameter tolerance of +/- 1”
40G/18ST2 - GALVANIZED STEEL PLATE
W: 185 lbs./83 kg. D: 40”/101cm H: .5”/12.7mm
Accommodated Mast: 2”/50mm (18ST2) Use: FREE-STANDING OR TABLE
CAN BE STACKED
18ST2 STEM REQUIRED
150A/18ST2 - PREMIUM ALUMINUM CONCRETE W: 150 lbs./68 kg. D: 30”/76cm H: 4”/10cm
Accommodated Mast: 2”/50mm (18ST2) Use: FREE-STANDING OR TABLE
18ST2 STEM REQUIRED
BK WH BZ SM
BZ2-SM - IN-GROUND MOUNTING STEM W: 11 lbs./5 kg. D: 4”/10cm H: 16”/40cm
Accommodated Mast: 2”/50mm
Use: IN-GROUND MOUNT INSTALLATION
Removable stem
SM
SPECIFIC MOUNTS - NOVA / G-SERIES 50
